Ubiquiti EdgeRouter PoE in the lab

August 5, 2015
0 Comments

Today, my Ubiquiti EdgeRouter POE arrived in the house. I got it hooked up to both UPC connections (as secondary connections) and all seems to be working grand. Some notes i wanted to put up here:

  • out of the box, the install was quite simple. set my Ethernet connection to a static ip in the 192.168.1.x/24 range,
    using 192.168.1.1 as gateway and dns, and then point at http://192.168.1.1 for admin. login (ubit for both username and
    password) and heay presto. I was asked did i agree to the license, and then im in.
  • by default, NAT is off… i turned it on, and enabled DNS and was able to surf.
  • I also noticed the software was out of date… Oddly, there did not seem to be an option to update automatically, but
    you can manually download the tar and upload it, which i did.
  • so far, so good… not sure yet if i will be using it as my main router, but it may end up being a VoIP router.

Finally, speed test result below:

More Ubiquiti stuff arriving tomorrow… will post more stuff then.

Network and HomeLab V.Next (Part 3)

July 15, 2015
0 Comments

So, this part of my article set will be talking specifically about the router and wireless network. At the moment, my router is way overkill:

  • Old HP Proliant ML110 G5
  • Intel Core2Quad Q6600
  • 8 Gb RAM
  • total of 12 Gigabit network cards (of which 4 are currently used…)
  • 500Gb HDD

I have been playing with some networking in the house and have managed to build some VLANs. The modems are connected both directly to the Router
and to a dedicated switch port for a given VLAN. The plan for the upgrade, which i hope to complete sooner than the rest of the network is as
follows:

  • get the ML110 running ESXi and visualize PFSense. Give it 2gb of RAM and some processor.
  • take some of the network cards out of the box. It does not need 12 ports, but maybe leave the 2 quad ports in there. They should be connected
    to the main switch trunked. 8 may be overkill, but i never do things by half.
  • the PFSEnse VM should be connected to all 3 WAN VlANs (900, 901 and 902) and should also have at least one port to the LAN. There may also be
    other ports for other internal VLANs.

with the spare processor, i can then add other (small) VMs to this machine.

Network and HomeLab V.Next (Part 2)

June 23, 2015
0 Comments

So, in my last post i talked about the requirements for the home lab, and in this post, im going to talk about a few more updates i have made in the last few weeks.

First, the processors: in the first post, i talked about Xeon D or Xeon E3… Well, i missed one… The Xeon E5. I have 2 of these in GodBox 2, and you can get them into a microATX board. There does seem to be some limits with the microatx boards, but hopefully enough searching will find me what i am looking for. Ideally, i want it to take “normal” DDR3/4 memory (not SODIMMs like the ASRock one above) and also take enough of them to run 64 or 128Gb of ram (thinking 8 would do the job!). Also, i would like to have 4 GigE ports onboard and 1 management port. 4 onboard is not a hard requirement: If i can get one with 2 ports, i can always get a 4 port card for the PCI-Express slot… Finally, i would like it to have at least 6 SATA ports and possibly an MSATA port. Thinking Boot off MSATA (Windows Server 2016 Nano Server would be used), 2 SSDs and 4 HDDs. Using Storage Spaces, use the 2 SSDs as “Fast” storage for the pool.

I also think i moved off the idea of 10Gb. I like the idea of it, but given a small 10Gb switch costs upwards of a grand, and the plan is to build a machine for that price, i would prefer a fifth machine and using my existing Cisco 48 port switch and leave 10Gb as a future upgrade.

Also, changed from last time round is machine count. Originally i was saying 3-4 machines… now i am thinking 6-7… 5-6 of them should be Hyper-V boxes and the last one would be a Media Box.

I also think the Synology or SAN requirement is out… Hyper-V can be setup to do replication between hosts, and with a 4Gb link to the LAN, i think i should be OK. Also, if i have the media box separate, i should be ok there too. I will detail the media center in a later post.

So, any suggestions or thoughts on what should and shouldn’t be looked at?

Network and Homelab V.Next (Part 1)

June 14, 2015
0 Comments

So, its that time again… HomeLab upgrade time… Or at least the planning for it. I am in the process of rebuilding my home lab, which involves pull all old servers out of the rack and replacing them with new ones… It also means rewriting the network, possibly upgrading some existing gear and hopefully getting the whole lot done on a budget of some sort…

So, why? Well, biggest reason for all this is currently heat and power usage. We use about 4-6x more electricity than the average house here in Ireland, which means our electricity bill is fairly high. It also means that the lab, which is also my office/bedroom, gets quite warm and uncomfortable during the summer month. There is an Air-Con unit in the room, and, well, that’s costing the most on electricity!

So, what I got is a basic overview of what I want from the homelab and hopefully in the next post, I will have an idea of what it will look like..

  • 3-4 machines running a Hyper Visor (HyperV, VMWare ESXi or other). Leaning more towards Hyper-V purely because its what I got currently and its what we use in our main office.
  • each machine should be connected to at least 2 networks: one for storage and migration, one for “public” to the LAN. There may be more VLANs for other networks, but 2 is a start.
  • ideally, 10Gb connections would be nice, but multiple 1Gb connections would also work.
  • shared storage (iSCSI, SMB3, etc) would also be a nice to have, but may bump up the server count (not actually a problem) but would increase power and cooling costs. An off the shelf box, like a Synology could do the job…
  • Lower power usage and less heat produced is also a major requirement. Most of the boxes I am decommissioning are older Xeon hardware (5000 series upto a 5200 series process and even an older Xeon P4!). The newer Xeon E3 and the even newer Xeon D are a lot more efficient, use less power, produce less heat and are way faster than what I currently have. The E3 can use up to 32Gb of RAM and the Xeon D top out at 128Gb… Me being me would like more than 32Gb RAM… 🙂
  • smaller machines would also be nice. I have been looking at both Xeon D and Xeon E3 Mini-ITX boards and cases for them. I do have a half height Dell Rack, which I host these machines, and ideally, these machines should be rack mountable, but micro ATX cases could work. 2 per shelf would work grand.
  • Onboard IPMI and KVM support is something I want too… I do have a KVMoIP switch in the house, and it works, most of the time, but getting a box that has this embedded into the board would be ideal… A lot of the server boards had it as standard or allowed it to be speced, so that’s all good.
  • I am also thinking of upgrading the router to a similar spec board… Possibly a Xeon E3, or even an i5…. Ideally it should have IPMI and KVMoIP on board and should produce less heat. Biggest issues is getting enough network cards into the box…

These are my requirements at a high level overview. Over time things may change, but lets see how we get on…

PFSense with Multiple Public IPs

May 30, 2015
0 Comments

So, a few weeks back, i got my hands on a Hetzner Dedicated box. It has a quad core Xeon, 32Gb ram, 3x3Tb hdds, RAID controller and KVMoIP. one of the first thing i did was get myself a /29 IP pool (8 total, 6 usable IPs). There where already 3 IPs given to me: 1 for the KVM, one for the box itself, and 1 as the router for the IP block.

So, i need to setup my own router, so i picked PFSense since its what i run in house. I gave it 2 network connections: 1 connected to the main network adapter on the VMWare ESXi box (public) and one to a virtual switch, which is only used by VMs. The public is the WAN link and it gets a static IP from Hetzner, and the virtual switch is then my “LAN” link. This allows me to have standard NATed network connections to any VM i have, but then, what do i do with those IPs?

So, after a lot of digging, i found the answer. So, this should help.

  • Under firewall, click on Virtual IPs.
  • Click the plus. I then selected IP alias, selected the WAN interface and set the IP to my first public IP i wanted to give. in my case, i was given a /29 block, and my first address was 176. This is the network address. I used 177. Likewise, my last address is 183, but that cannot be used either as its a broadcast address. give it a description and then hit OK. Repease for all IPs you want to use. TIP: Give each a meaningful description!
  • Next, click firewall, NAT and 1:1. Click the add button and select your interface as WAN. set the External Subnet IP as the one you want to use and your internal IP as the machine that will have it. Thats all i did on that screen…
  • Then go to Firewall, NAT, outbound… this is where things got complicated. Set the mode to “Manual outbound NAT rule generation (AON – Advanced Outbound NAT)” and click save.
  • Then create a new rule: Interface: WAN, Source, Network, IP of the internal machine and then under translation, under address select the IP you want to give it. If you followed my tip in step 2, you should see the descriptions in here.

After saving everything and reloading the firewall, visiting a page like WhatsMyIP or ICanHazIP should show you your public IP. You can then create firewall rules to allow access. Quick idea would be:

Firewall/Rules, Add, Interface WAN, Destination: Local IP you want to use, and give whatever “normal” rules you would (HTTP, lock down to source address, etc). Click apply and hitting that address using what ever method (SSH, HTTP, etc) should work.

YMMV, but hopefully this helps! Any questions, leave a comment.

Quick tip for internet facing ESXi servers

May 20, 2015
0 Comments

Quick tip for all you with internet facing VMWare ESXi Hosts. I
have just got my hands on a box on the Hetzner network (more on
that later) and using their LARA system i installed ESXi on it. All was good, then I tried login in a couple hours later and i kept getting errors about my password being wrong… So, i tried a few more times, got pissed off and rebooted the box (had to do a hard reboot, since i couldn’t even get in over KVM). I though this was a hardware issue, or a config issue, and left it… yesterday, i had the console open most of the day, and when looking at something i noticed this:

Well, that’s why I couldn’t login! So, tip: create a second user account, name it something other than root, give it a secure password and use that to login to your ESXi box. Ideally, your ESXi box should be behind a firewall, but in the case of a dedicated server, that may not be financially feasible… Hope this helps someone!

VLANs, Wifi and Mikrotik

May 10, 2015
0 Comments

About a month ago, while i was recovering from surgery, i attended a Webinar on
Cisco Meraki devices. After the webinar, i was contacted by Maraki and given a MR18 with a 3 year license, to play with and evaluate. So, i set it up in the house and all was good.

Thing is, the wifi in the house was grand previously. I have a Routerboard RB951G which does the job and has no issues. And because i am mostly offsite in the office i work, and because i need to remotely manage the network, the MR18 is going into the office from tomorrow morning. I may talk about the MR18 and the rest of the Meraki gear later on, but this is not that post. This post is about something the MR18 did, and i wanted to do on the RB951.

So, the MR18 allows you to create multiple Wifi SSIDs, each with different encryption and security and can use different VLANs. Now, the Mikrotik does the same, but the VLANs stuff is not that easy to figure out. but essentially, what i needed to do was as follows:

create your new wifi SSIDs:

/interface wireless
add master-interface=wlan1 name=wlan1.10 ssid=vlan10
add master-interface=wlan1 name=wlan1.20 ssid=vlan20

next, create your vlans. these need to be connected back to your main
ethernet connection. In the case of my RB951, there are 5 ethernet
ports. 1 is the gateway back to my Cisco switch and on to my PFSense router. 2-5 are all slaves of number 1, which is a master. So, 1 is essentially a trunk network. So, vlans are created on that.

/interface vlan
add name=vlan10 interface=ether1-gateway name=ether1.10 vlan-id=10
add name=vlan20 interface=ether1-gateway name=ether1.20 vlan-id=20

next, a bridge to connect them

/interface bridge
add name=vlan10
add name=vlan20

and connect them to the bridge

/interface bridge port
add bridge=vlan10 interface ether1.10
add bridge=vlan10 interface wlan1.10
add bridge=vlan20 interface ether1.20
add bridge=vlan20 interface wlan1.20

And thats all i needed to do. I have a Sophos UTM Home edition running on a vm for testing, which vlan10 is connected to. It has an upstream connection back to the PFSense box, which has it firewalled off and allows it outside the network, not nothing else. I am planning on doing this with other firewalls, just to do some testing with. This allows me to connect my phone or laptop, or any other wifi device, to a given wifi connection and then be on my way. I also have an older Dell PowerConnect switch, which, if i ever get around to it, will have multiple connections back to the Cisco and then allow physical devices to connect to different vlans.

Any questions, comments, etc, leave a comment blow.

Using git and Route53 together

May 7, 2015
0 Comments

so, earlier on today, i was talking about using Git with a DNS service called LuaDNS to update your DNS records. Well, thing is, i have 30+ domains registered, and of them about 25 are hosted on Amazon’s Route53. So, moving ALL of them seems, well at the moment, excessive… So, i went digging…

there is a tool called cli53 which will allow you to manage route53 objects from the command line. It can also export your zones to BIND format and then re-import them if you have made changes… This all came out of a blog post by the guys and gals at netguru who showed how they integrate their DNS records with their Continuous Integration… Now, i have not gotten to that stage, just yet, but its only 1 step more down the road… but I don’t have my zones in bind format… So, how do i do that?

I tweaked their block of ruby code (first time playing with ruby, be gentle with me) and got the following:

essentially, it runs cli53 (you may need to change your path) and then creates .bind files for each zone.

then, using their code below, you can re-import them to Route53:

i have exported all mine, added them to git and done some testing… All seems to be in order… once i do some tweaks, i can get that CI piece working and it should be all magic…

Git Push DNS

May 7, 2015
0 Comments

There are now a lot of services that have “git push” options available… you can build websites with
Azure and Github, books using ShareLaTeX and now, DNS using LuaDNS. I have one zone
running at the moment (tiernanotoole.net) and you can see the DNS records on github here. I am
tempted at moving other records over soon… but i am currently on Amazon Route53 and 1: its works, so
dont break it, and 2, not sure how to bulk export records from Route53 to Bind or Lua format.

[update] 2 quick updates: 1) their free account, which is what i am using, allows 3 domains and 30 host
records. they also charge less than Route53:

  • route 53 for 10 domains per year cost 50c per domain (first 25) per month, then query charges. total,
    about $60 + queries (@40c per million).
  • luadns cost $29 a year for 10 domains, 5 million (ish) querys a month and 500 host records…

I think i have nearly 30 domain on AWS… so, their $59 a year package, which include 30 domains, would
probably save me money…

and 2) i forgot about one of those git push services… DeveloperMail is a service, for developers,
for managing email servers. IMAP, SMTP, Git… all supported! just signed up… $2 a month per user. Lets
see how this works…

Bulk compressing images for the Web

April 29, 2015
0 Comments

Now that all my sites are running Jekyll I am trying to get them optimized for SPEED which meant
looking at all the stuff that takes time to download… There are more tweaks (and possibly posts) coming down
the road, but to start, I needed to look at images.

First things first. I’m running this on a Sabayon Linux box, so some of the install commands will be different… (Also, i do need to explain why I moved from Windows to Linux on the GodboxV2, but that’s a different post…)

First, install OptiPNG (they have a Windows build too…) and JPEGOptim

sudo equo install optipng
sudo equo install jpegoptim

[UPDATE] I tried this on an Ubutnu Box, and to install both of these, the package names are the same. so, to install both:

sudo apt-get install optipng jpegoptim

Next, using the Linux find command (this should work also on OSX…) run OptiPNG and JPEGOptim on all pngs and
jpgs in your given directory:

find . -iname "*.png" -exec optipng {} \;
find . -iname "*.jpe?g" -exec jpegoptim {} \;

depending on how many images (and how fast your machine is) it should take a min or two…

That’s it! I did a git status, which showed me all the changed images, and then deployed the Jekyll sites… All
good! That’s it!
